Concrete Tile Fixing Kit

From: £171.08 (Exc. VAT) - £205.30 - Inc. Vat

This solar panel fixing kit setup, provides weatherproof installation of concrete tile/ pantile roof types.

FIXING CLAMPS ARE AVAILABLE IN BLACK OR SILVER ANODISED FINNISH (PLEASE ADVISE

Look at this solar flash instructional booklet to understand the solar bracket assembly principle.

See the drop-down menu below to select the solar fixing kit panel number amount required.
We may use Vario 1 or Vario 2 brackets if stock levels are low. Our kits will accept all solar PV panels.

Select from product options

MAKE YOUR SELECTION - Concrete Tile Fixing Kit

Note: Due to the length and overall weight of items within our range of fixing kits, specialized couriers are used, resulting in slightly higher delivery costs and times, subject to courier availability. We aim to ship items within 48 hours of order time.
For more information, you can read through our Delivery Policy

ImageProduct OptionPrice (exc. VAT)Quantity-
K2 vario 2 bracket Pan tile solar fixing15 panel x 2 rows PORTRAIT roof fixing kit c/w FLASHING£1,675.00
Add to basket
K2 vario 2 bracket Pan tile solar fixing6 panel x 2 rows PORTRAIT roof fixing kit c/w FLASHING£847.49
Add to basket
K2 vario 2 bracket Pan tile solar fixing1 panel x 1 row LANDSCAPE roof fixing kit c/w FLASHING£222.47
Add to basket
K2 vario 2 bracket Pan tile solar fixing2 panel x 1 row LANDSCAPE roof fixing kit c/w FLASHING£302.04
Add to basket
K2 vario 2 bracket Pan tile solar fixing3 panel x 1 row LANDSCAPE roof fixing kit c/w FLASHING£498.58
Add to basket
K2 vario 2 bracket Pan tile solar fixing1 panel x 1 row PORTRAIT roof fixing kit c/w FLASHING£171.08
Add to basket
K2 vario 2 bracket Pan tile solar fixing2 panel x 1 row PORTRAIT roof fixing c/w FLASHING£302.04
Add to basket
K2 vario 2 bracket Pan tile solar fixing3 panel x 1 row PORTRAIT roof fixing kit c/w FLASHING£498.58
Add to basket
K2 vario 2 bracket Pan tile solar fixing4 panel x 1 row PORTRAIT roof fixing kit c/w FLASHING£531.57
Add to basket
K2 vario 2 bracket Pan tile solar fixing5 panel x 1 row PORTRAIT roof fixing kit c/w FLASHING£653.42
Add to basket
K2 vario 2 bracket Pan tile solar fixing6 panel x 1 row PORTRAIT roof fixing kit c/w FLASHING£651.39
Add to basket
K2 vario 2 bracket Pan tile solar fixing8 panel x 1 row PORTRAIT roof fixing kit c/w FLASHING£1,037.20
Add to basket
K2 vario 2 bracket Pan tile solar fixing8 panel x 2 rows PORTRAIT roof fixing kit c/w FLASHING£1,063.13
Add to basket
K2 vario 2 bracket Pan tile solar fixing9 panel x 1 row PORTRAIT roof fixing kit c/w FLASHING£1,159.05
Add to basket
K2 vario 2 bracket Pan tile solar fixing10 panel x 2 rows PORTRAIT roof fixing kit c/w FLASHING£1,306.84
Add to basket
K2 vario 2 bracket Pan tile solar fixing12 panel x 2 rows PORTRAIT roof fixing kit c/w FLASHING£1,522.18
Add to basket
K2 vario 2 bracket Pan tile solar fixing14 panel x 2 rows PORTRAIT roof fixing kit c/w FLASHING£1,634.74
Add to basket
K2 vario 2 bracket Pan tile solar fixing16 panel x 2 rows PORTRAIT roof fixing kit c/w FLASHING£1,840.48
Add to basket
K2 vario 2 bracket Pan tile solar fixing7 panel x 1 row PORTRAIT roof fixing kit c/w FLASHING£881.27
Add to basket

Description

CONCRETE TILE SOLAR FIXING KIT

IN PORTRAIT ORIENTATION.

A fixed bracket kit for new build concrete style roof tiles or a vario 1 adjustable bracket for older uneven roofs.

In the notes, please advise which bracket is required.

On-roof standard connection kits in portrait orientation.

Can be used on many marley or any concrete type tiles. Each concrete tile solar fixing kit will include all equipment fixing parts required. Some installations may require further parts, if in doubt please ask. Roof installation kits in portrait to match your own panels.

Each standard kit includes rails, end caps, fixing brackets, bracket flashing kit, stainless fixing screws, T bolts and nuts, rail joiners and fixing clamps to match your solar modules.

All parts included in this kit are as follows:

Click here to download – Pan Tile Brochure

Note! We will need to know the module size prior to dispatching equipment kit, due to the many different sized solar panels that are now on the market.

PLEASE ADVICE CLAMP SIZE TO MATCH YOUR SOLAR MODULES:

Check your solar panel size before placing a kit order

Setting out measurements are usually dependent on the roof timbers. You should take a measurement of your roof, as our kits are matched to 450mm spacing. As all UK roofs are different, this is only a guide. Therefore the installer is responsible for all measurements.

Clamp sizes available: 30mm, 34-36mm, 37-38mm, 39-41mm, 42-43mm, (44-50mm limited stock)

If you do not tell us the SOLAR PANEL SIZE you are using: We will send out universal mid and end clamps.

Universal clamps will suit solar panels sizes = 30-43mm

We offer concrete tile solar panel fixing kits based upon 400-450mm rafter spacings and tile sizes. If your roof is different, then please advise. As the amount of brackets could alter depending on the spacing.

Data

Fixing arrangement example concrete/pantile layout, for Standard and Extra Large size solar PV panels.

All of our concrete/pantile solar panel fixing kits contain these parts, to affix extra larger solar panels.


Concrete/pantile bracket numbers as just a guide with rafter spacing @ 450mm between timbers.


1 panel kit x 1 row CONCRETE/PANTILE PORTRAIT roof fixing kit: = 4 brackets + 8 wood screws + 4 flashing kits + 4 T bolts + 4 nuts + 1 rail @ 2.5m + 4 rail end caps + 4 universal end clamps + 4 cable tidy clips + 4 cable ties.


1 panel kit x 1 row CONCRETE/PANTILE LANDSCAPE roof fixing kit: = 5 brackets + 10 wood screws + 5 flashing kits + 5 T bolts + 5 nuts + 2 rails @ 2.5m + 4 rail end caps + 4 universal end clamps + 4 cable tidy clips + 4 cable ties.


2 panel kit x 1 row CONCRETE/PANTILE PORTRAIT roof fixing kit: = 7 brackets + 14 wood screws +7 flashing kits + 7 T bolts + 7 nuts + 2 rails @ 2.5m + 4 rail end caps + 4 universal end clamps + 2 universal mid clamps + 8 cable tidy clips + 8 cable ties.


2 panel kit x 1 row Concrete/pantile LANDSCAPE roof fixing kit: = 8 brackets + 16 wood screws + 8 flashing kits + 8 T bolts + 8 nuts + 2 rails @ 2.5m + 2 rails @ 3.65m + 2 rail connectors + 4 rail end caps + 4 universal end clamps + 2 universal mid clamps + 8 cable tidy clips + 8 cable ties.


3 panel x 1 row Concrete/pantile PORTRAIT roof fixing kit: = 11 brackets + 22 wood screws + 11 flashing kits + 11 T bolts + 11 nuts + 2 rails @ 3.65m + 4 rail end caps + 4 universal end clamps + 4 universal mid clamps + 12 cable tidy clips + 12 cable ties.


3 panel x 1 row Concrete/pantile LANDSCAPE roof fixing kit: = 12 brackets + 24 wood screws + 12 flashing kits + 12 T bolts + 12 nuts + 4 rails @ 3.65m + 2 rail connectors + 4 rail end caps + 4 universal end clamps + 4 universal mid clamps + 12 cable tidy clips + 12 cable ties.


4 panel x 1 row Concrete/pantile PORTRAIT roof fixing kit: = 14 brackets + 28 wood screws + 14 flashing kits + 14 T bolts + 14 nuts + 4 rails @ 2.5m + 2 rail connectors + 4 rail end caps + 4 universal end clamps + 6 universal mid clamps + 16 cable tidy clips + 16 cable ties.


5 panel x 1 row Concrete/pantile PORTRAIT roof fixing kit: = 15 brackets + 30 wood screws + 15 flashing kits + 15 T bolts + 15 nuts + 2 rails @ 3.65m + 2 rails @ 2.5m + 4 rail connectors + 4 rail end caps + 4 universal end clamps + 8 universal mid clamps + 20 cable tidy clips + 20 cable ties.


6 panel x 1 row Concrete/pantile PORTRAIT roof fixing kit: = 18 brackets + 36 wood screws + 18 flashing kits + 18 T bolts + 18 nuts + 4 rails @ 3.65m + 4 rail connectors + 4 rail end caps + 4 universal end clamps + 10 universal mid clamps + 24 cable tidy clips + 24 cable ties.


6 panel x 2 rows Concrete/pantile PORTRAIT roof fixing kit: = 22 brackets + 44 wood screws + 22 flashing kits + 22 T bolts + 22 nuts + 4 rails @ 3.65m + 4 rail connectors + 8 rail end caps + 8 universal end clamps + 8 universal mid clamps + 24 cable tidy clips + 24 cable ties .


7 panel x 1 row Concrete/pantile PORTRAIT roof fixing kit: = 23 brackets + 46 wood screws + 23 flashing kits + 23 T bolts + 23 nuts + 4 rails @ 2.5m + 2 rails @ 3.65m + 4 rail connectors + 4 rail end caps + 4 universal end clamps + 12 universal mid clamps + 28 cable tidy clips + 28 cable ties.


8 panel x 1 row Concrete/pantile PORTRAIT roof fixing kit: = 25 brackets + 50 wood screws + 25 flashing kits + 25 T bolts + 25 nuts + 8 rails @ 2.5m + 6 rail connectors + 4 rail end caps + 4 universal end clamps + 14 universal mid clamps + 32 cable tidy clips + 32 cable ties.




8 panel x 2 rows Concrete/pantile PORTRAIT roof fixing kit: = 28 brackets + 56 wood screws + 28 flashing kits + 28 T bolts + 28 nuts + 8 rails @ 2.5m + 4 rail connectors + 8 rail end caps + 8 universal end clamps + 12 universal mid clamps + 32 cable tidy clips + 4 cable ties


9 panel x 1 row Concrete/pantile PORTRAIT roof fixing kit: = 27 brackets + 54 wood screws + 27 flashing kits + 27 T bolts + 27 nuts + 6 rails @ 3.65m + 6 rail connectors + 4 rail end caps + 4 universal end clamps + 16 universal mid clamps + 36 cable tidy clips + 36 cable ties.

10 panel x 2 rows Concrete/pantile PORTRAIT roof fixing kit: = 32 brackets + 64 wood screws + flashing kits + 32 T bolts + 32 nuts + 4 rails @ 3.65m + 2 rails @ 2.5m + 8 rail connectors + 8 rail end caps + 8 universal end clamps + 16 universal mid clamps + 40 cable tidy clips + 40 cable ties.



12 panel x 2 rows Concrete/pantile PORTRAIT roof fixing kit: = 36 brackets + 72 wood screws + 36 flashing kits + 36 T bolts + 36 nuts + 8 rails @ 3.65m + 6 rail connectors + 8 rail end caps + 8 universal end clamps + 20 universal mid clamps + 48 cable tidy clips + 48 cable ties.


14 panel x 2 rows Concrete/pantile PORTRAIT roof fixing kit: = 38 brackets + 76 wood screws + 38 flashing kits + 38 T bolts + 38 nuts + 8 rails @ 3.65m + 4 rails @ 2.5m + 8 rail connectors + 8 rail end caps + 8 universal end clamps + 24 universal mid clamps + 56 cable tidy clips + 56 cable ties.


16 panel x 2 rows Concrete/pantile PORTRAIT roof fixing kit: = 46 brackets + 92 wood screws + 46 flashing kits + 46 T bolts + 46 nuts + 8 rails @ 3.65m + 4 rails @ 2.5m + 8 rail connectors + 8 rail end caps + 8 universal end clamps + 28 universal mid clamps + 64 cable tidy clips + 64 cable ties.
